Main Function
1) Automatically finish all production process,small volume,operate easily.
2) Schneider PLC controller,touchscreen with process visualization all pocess display,real time monitoring.
3) Depending on the capsules stackable or not stackble design, the machine come with stack channel for manual loading or with automatic capsule feeding system.
4) Vaccum feeding machin,screw feeding machine,elevator machine,different conveyor methods,automatically send materials,simple and convenient.
5) Automatically pressing powder,clean cup’s top rim,get good sealing effect.
6) Cutting and sealing lids in one step,lids from roll and lids magazine.
7) Nitrogen flush function:From capsules feeding station to sealing station,a flow process with revised Nitrogen atmosphere 2% residual Oxygen content,prolong product shelf life.
8) Heat sealing or Ultrasound sealing with material supplied on reels or magazines.
9) Possibility to handle different capsule styles with easy size changeover.
10) Remote controller,diagnose machine’s problem and solve it and monitoring machine’s running at outside,revise computer program.
11) Autoamtically count finished product’s quantity,no cup,no filling,no sealing.
12) Whole machine’s frame adopt 304 stainless steel material,high hardness.It is also accordance with food hygiene license.
Model |
SKP-1 |
Filling weight range |
0-20g*n(Option) |
Filling accuracy |
±0.15g |
Speed |
50 pcs/per minute |
Hopper capacity |
10-24L可选110L |
Control system |
PLC |
Displayer |
7 inch Touchscreen |
Power supply |
AC220V/380V 50Hz/60Hz 5KW |
Dimension |
5296(L)×2686(W)×2487(H)mm |
Weight |
1000kg |
Gross weight |
1100kg |
